Description
- Working pressure up to 1.36 kg/cm2 (20 P.S.I.G), Vaccum up to 250 mm (10″) of Hg.
- Construction S.S. 316 or S.S 304 chamber and jacket of boiler grade steel with reinforcements.
- Optical door inner construction either S.S.304 or M.S. lined S.S.
- Radial Locking System, Sliding door with tongue & groove system for big size models. Fitted with Silicon Gasket.
- Multiport value operation available.
- Large capacity units with direct steam operation have diaphragm type PRV,
- Small capacity units with generator with pressure switch with low water cut-off system.
- Available with Double Door System.
- Optional accessories low water+Mechanical Timer + Fully Automatic
- Microprocessor-Pre & Post Vacuum
| Cat. No. | DiaxDepth |
| 57001 | 400 mm x 600 mm |
| 57002 | 400 mm x 900 mm |
| 57003 | 400 mm x 1200 mm |
| 57004 | 500 mm x 900 mm |
| 57005 | 500 mm x 1200 mm |
| 57006 | 400 mm x 1500 mm |
| 57007 | 600 mm x 1200 mm |
| 57008 | 600 mm x 1100 mm |
| 57009 | 600 mm x 800 mm |
SIZE/ CAPACITY: 40LTR- 110LTRS
